ZX62D-AB-5P8(30)
Manufacturer:
Hirose Electric
Mfr.Part #:
ZX62D-AB-5P8(30)
Datasheet:
Description:
USB Connectors SMD/SMT Type B Receptacle USB 2.0
| Parameter | Value |
|---|---|
| Length | 8.65 mm |
| Width | 5.3 mm |
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -30 °C |
| Height | 2.5 mm |
| Packaging | Reel |
| Voltage Rating | 30 V |
| Lead Free | Lead Free |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Gold, Nickel |
| Pitch | 650 µm |
| Type | Type B |
| Current Rating | 1.8 A |
| Orientation | Right Angle |
| Lifecycle Status | Production (Last Updated: 10 months ago) |
| Gender | Receptacle |
| Shielding | Shielded |
| Number of Contacts | 5 |
| Data Rate | 480 Mbps |
| USB Standard | USB 2.0 |
| Connector Type | Receptacle, USB |
| Number of Positions | 5 |
| Number of Ports | 1 |
| Contact Voltage Rating (AC) | 30 V |
| Schedule B | 8536695050 |
| Contact Pitch | 0.65 mm |
Stock: 3598
Distributors
pcbx
pcbxUnit Price$0.56938
Ext.Price$0.56938
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.56938 | $0.56938 |
| 10 | $0.46337 | $4.63370 |
| 25 | $0.40182 | $10.04550 |
| 50 | $0.38923 | $19.46150 |
| 100 | $0.37703 | $37.70300 |
| 300 | $0.35410 | $106.23000 |
| 500 | $0.33257 | $166.28500 |
| 1000 | $0.32573 | $325.73000 |
| 3000 | $0.28726 | $861.78000 |
